LTR 18-30 - diely1

Podrobný popis

POS | Č. výrobku | Opis |

1 | 2.444-014.0 | Cievka so silonom 1,6mm pre 18V Vyzinac |

4 | 6.444-094.0 | Locking material |

5 | 6.444-087.0 | skrutka |

7 | 6.445-204.0 | Set covering cap shaft |

9 | 6.444-085.0 | Guide |

10 | 6.444-081.0 | Plate |

11 | 6.444-091.0 | Pružina |

12 | 6.444-080.0 | Pivot switch |

13 | 6.444-069.0 | Cable |

14 | 6.444-072.0 | Telescopic tube |

15 | 6.444-084.0 | Handhold |

16 | 6.444-074.0 | Wing nut |

17 | 6.444-089.0 | Screw |

18 | 6.445-203.0 | Handhold few |

21 | 6.444-082.0 | Pusher |

22 | 6.444-092.0 | Spring |

23 | 6.444-083.0 | Pusher lock |

24 | 6.444-093.0 | microswitch |

25 | 6.444-070.0 | Cable |

26 | 6.444-090.0 | Spring |

27 | 4.444-128.0 | Battery rail complete 18V |

28 | 6.444-071.0 | Retainer coil |

30 | 6.444-075.0 | Engine holder |

31 | 6.444-068.0 | Motor 18V DC |

32 | 6.445-205.0 | Set motor housing |

34 | 6.444-115.0 | Blade |

35 | 6.444-430.0 | Cover |

40 | 5.444-049.0 | Label Battery Power 18V LTR |

50 | 5.444-050.0 | Label Battery Power 18V LTR |

60 | 5.444-052.0 | Label with Kaercher logo -18V LTR |

70 | 5.444-051.0 | Label cutting width 30cm LTR |

80 | 5.444-055.0 | Label safety information 18-30 LTR |

90 | 5.444-053.0 | Label Auto line feed -18V LTR |

100 | 5.444-056.0 | Label signet |

110 | 5.444-067.0 | Label Noise 96 dB |
